Terraform Variable and DataSource Example
Terraform Variables and Datasources
Pre-requisite
- Create a key(devops in this example I have taken) in AWS EC2 Key pairs which we will reference in our EC2 Instance.
- Get latest EC2 AMI ID Using Terraform Datasources concept
- We are also going to use existing EC2 Key pair terraform-key
- Use all the above to create an EC2 Instance in default VPC
Step-01: Example Topics to cover
- Terraform Concepts
- Terraform Input Variables
- Terraform Datasources
- Terraform Output Values
Below Input variables will be created
- AWS Region
- Instance Type
- Key Name
Define Security Groups and Associate them as a List item to AWS EC2 Instance
- vpc-ssh
- vpc-web
Learn about Terraform Output Values
- Public IP
- Public DNS
Step-02:- Creating Variables
variables.tf
# AWS Region
variable “aws_region” {
description = “Region in which AWS Resources to be created”
type = string
default = “ap-south-1”
}
# AWS EC2 Instance Type
variable “instance_type” {
description = “EC2 Instance Type”
type = string
default = “t2.micro”
}
# AWS EC2 Instance Key Pair
variable “instance_keypair” {
description = “AWS EC2 Key pair that need to be associated with EC2 Instance”
type = string
default = “devops”
}
# AWS Security Group
variable “sg” {
description = “AWS Security Groups”
type=list
default = [“vpc-ssh”,“vpc-web”]
}
Reference the variables in base.tf fies
base.tf file
provider “aws”{
region=var.aws_region
}
Step-03: ec2securitygroups.tf – Define Security Group Resources in Terraform
# Create Security Group – SSH Traffic
resource “aws_security_group” “vpc-ssh” {
name = var.sg[0]
description = “Dev VPC SSH”
ingress {
description = “Allow Port 22”
from_port = 22
to_port = 22
protocol = “tcp”
cidr_blocks = [“0.0.0.0/0”]
}
egress {
description = “Allow all ip and ports outboun”
from_port = 0
to_port = 0
protocol = “-1”
cidr_blocks = [“0.0.0.0/0”]
}
}
# Create Security Group – Web Traffic
resource “aws_security_group” “vpc-web” {
name = var.sg[1]
description = “Dev VPC web”
ingress {
description = “Allow Port 80”
from_port = 80
to_port = 80
protocol = “tcp”
cidr_blocks = [“0.0.0.0/0”]
}
ingress {
description = “Allow Port 443”
from_port = 443
to_port = 443
protocol = “tcp”
cidr_blocks = [“0.0.0.0/0”]
}
egress {
description = “Allow all ip and ports outbound”
from_port = 0
to_port = 0
protocol = “-1”
cidr_blocks = [“0.0.0.0/0”]
}
}
Step-04: ami-datasource.tf – Define Get Latest AMI ID for Amazon Linux2 OS
# Get latest AMI ID for Amazon Linux2 OS
# Get Latest AWS AMI ID for Amazon2 Linux
data “aws_ami” “amzlinux2” {
most_recent = true
owners = [ “amazon” ]
filter {
name = “name”
values = [ “amzn2-ami-hvm-*-gp2” ]
}
filter {
name = “root-device-type”
values = [ “ebs” ]
}
filter {
name = “virtualization-type”
values = [ “hvm” ]
}
filter {
name = “architecture”
values = [ “x86_64” ]
}
}
Step-05: ec2instance.tf – Define EC2 Instance Resource
# EC2 Instance
resource “aws_instance” “myec2vm” {
ami = data.aws_ami.amzlinux2.id
instance_type = var.instance_type
key_name = var.instance_keypair
vpc_security_group_ids = [aws_security_group.vpc-ssh.id, aws_security_group.vpc-web.id]
tags = {
“Name” = “EC2 Demo “
}
}
Step-06: outputs.tf – Define Output Values
# Terraform Output Values
output “instance_publicip” {
description = “EC2 Instance Public IP”
value = aws_instance.myec2vm.public_ip
}
output “instance_publicdns” {
description = “EC2 Instance Public DNS”
value = aws_instance.myec2vm.public_dns
}
Step-07: Execute Terraform Commands
# Terraform Initialize
terraform init
Observation:
1) Initialized Local Backend
2) Downloaded the provider plugins (initialized plugins)
3) Review the folder structure ".terraform folder"
# Terraform Validate
terraform validate
Observation:
1) If any changes to files, those will come as printed in stdout (those file names will be printed in CLI)
# Terraform Plan
terraform plan
Observation:
1) Verify the latest AMI ID picked and displayed in plan
2) Verify the number of resources that going to get created
3) Verify the variable replacements worked as expected
# Terraform Apply
terraform apply
[or]
terraform apply -auto-approve
Observations:
1) Create resources on cloud
2) Created terraform.tfstate file when you run the terraform apply command
3) Verify the EC2 Instance AMI ID which got created
Step-08: Clean-Up
# Terraform Destroy
terraform plan -destroy # You can view destroy plan using this command
terraform destroy
# Clean-Up Files
rm -rf .terraform*
rm -rf terraform.tfstate*
